BS-M240 Exit Motion Sensor + NU-06 12V DC Adapter
Micro wave motion detector
Adjust sensitivity potentiometer to adjust the size of the sensor range
Minimum sensing range 1.5 x 1.0 Meters
Maximum sensing range 4 x 2.5 Meters
Voltage: DC12V - 36V
Current consumption : Static 45 mA Dynamic 105mA (DC12V)
Operating Temp: -20~+60℃
Suitable Humidity: 0~90%(non-comdensing)
Dimension : 131L x 61w x 46H (mm)
NU-06 12V DC POWER SUPPLY CONTROLLER WITH RELAY FUNCTION AND NO - NC
Dimensions: 4.7'L x 3.7' W x 1.5' H (Inch)
Input Voltage: 110VAC~260VAC;50HZ~60HZ
Output Voltage: 12VDC; 3A
Output Contact: Access control, Electric Lock, Release Button
Time Relay: 0~15sec.
Standard Designe: Steel material, Painted
Protect Safely: Short Circuit protection
Suitable For : Access control, Electric lock
